1999-2006 DBC LS1/Vortec Standalone Harness with T56/Non Electric Transmission and EV6 Injectors


1 in stock (can be backordered)

Mass Air Flow *

Show Stopper Braided Loom? *

Our harnesses are designed for installing these new GM EFI engines into your ride, whatever it may be. This harness is specific for 1997-2006 Vortec and V8 Car engines with a Drive by Cable (Mechanical) Throttle Body and EV6 Injectors.


All harnesses are made with GM color coded TXL wire to meet or exceed OEM standards! All circuits that are ran by heat like the O2 sensor circuits are covered with 1200* Fiberglass Braid. We only use Delphi, Kostal, Bosch, Molex, and Yazaki connectors, terminals, and seals on our harnesses, just like an OEM harness. All connectors that have Connector Position Assurance Lock on a factory harness have them on our harnesses also. The harnesses also include a Delphi Grommet that can be positioned on the main harness line to seal your firewall. Harnesses are 5 foot long from the rear of the intake. This enables you to mount the PCM and Fuse Block in the passenger compartment. Harnesses are for pre-emissions vehicles or for off road use only.

We do offer braided loom as our Show Stopper option! This is typically not a stocked harness option. Lead times vary on the time of year, feel free to email or call Us to get the most up to date lead time for the Show Stopper Upgrade!

Harnesses do not have provisions for EGR, AIR, EVAP, or Rear O2 Sensors. We can add these for an additional cost, however in most cases they are not needed. IF EMISSIONS ARE NEEDED YOUR HARNESS WILL INCUR A LEAD TIME AND AN ADDITIONAL FEE.

Harnesses also require the removal of the VATS system from the PCM as well as the emissions removal from the PCM. This harness also requires the use of a Red and Blue PCM service numbers 12200411 or 9354896, also available through BP Automotive.

H307 h307 h-307 8307

Weight 9 lbs
Dimensions 14 × 14 × 8 in
